Custom LASIK or Wavefront LASIK:
Individualized Vision Correction

By Keith Croes; reviewed by Dr. Brian Boxer Wachler and Dr. Vance Thompson

On this page:

Custom LASIK surgery, also known as wavefront LASIK or wavefront-guided LASIK, uses 3-dimensional measurements of how your eye processes images to guide the laser in re-shaping the front part of the eye (cornea).

With a wavefront measurement system, some extremely precise, individualized vision correction outcomes may be achieved that would be impossible with traditional LASIK surgery, contact lenses or eyeglasses.

Click Here to Learn About Local LASIK Surgeons:

You should be qualified under Food and Drug Administration guidelines before custom wavefront LASIK would be considered for your eye condition. Depending on the custom laser system used and other factors such as appropriate thickness of your cornea, you might be considered a candidate if you have mild to moderately high degrees of common vision defects such as myopia, hyperopia and astigmatism.

With custom LASIK, your eye's ability to focus light rays is measured, and a 3-D map is created that demonstrates irregularities in the way your eye processes images. Information contained in the map guides the laser in customizing the treatment to reshape your eye's corneal surface so that these irregularities can be corrected. [See also: Wavefront Technology in Eye Exams]

Standard prescriptions for glasses, contacts, or traditional LASIK procedures can correct ordinary vision defects such as myopia, hyperopia, and astigmatism. But other irregularities associated with the eye's optical system could not be addressed until the advent of wavefront and related technology used in custom LASIK.

LASIK surgery

Wavefront LASIK creates a highly individualized laser correction of your eye's surface, guided by precise analysis of vision errors that occur as light rays travel through your eye.

Potential Benefits of Wavefront-Guided Custom LASIK

Wavefront technology is groundbreaking because it has the potential to improve not only how much you can see, visual acuity measured by the standard 20/20 eye chart, but also how well you can see, in terms of contrast sensitivity and fine detail. This translates into a reduced risk of post-LASIK complications, such as glare, halos, and difficulty with night vision.

How much you see depends on vision defects known as lower-order aberrations associated with common refractive errors including myopia, hyperopia, and astigmatism, which traditional LASIK can treat.

How well you see can depend on presence of the type and numbers of visual distortions known as higher-order aberrations, which can include irregularities other than common refractive errors. These higher-order aberrations can create problems such as decreased contrast sensitivity or night vision, glare, shadows, and halos. However, higher-order aberrations do not always affect vision. Unlike traditional LASIK, custom LASIK treats both lower- and higher-order aberrations. [See also: What Are Higher-Order Aberrations?]

Custom LASIK's advantage lies in the area of quality of vision:

  • Greater chance of achieving 20/20 vision
  • Greater chance of achieving better than 20/20 vision
  • Reduced chance of losing best-corrected vision
  • Reduced chance of losing visual quality or contrast sensitivity
  • Reduced chance of night-vision disturbances and glare


Contact Lenses

LASIK & Vision Surgery

Eyeglasses

Sunglasses

Eye Exams

Problems & Diseases

  Cataracts

  Glaucoma

  Macular Degeneration

  Other Diseases

Vision Insurance

Low Vision

Computer Vision

Sports Vision

Nutrition & Eyes

Buy Smarter

Vision Over 40

Vision Over 60

Children's Vision

Teens

Resources

Home

Learn about iLASIK advanced laser vision correction

Tears Again Hydrate gels contain omega-3 fatty acids to treat dry eyes

Get no-interest financing on LASIK today from CareCredit

LasikPlus Vision Centers. Schedule Your Free LASIK Exam Online Today!

Similasan eye drops relieve and soothe dry eyes after LASIK





Potential also exists for custom LASIK to treat those people who have lost best-corrected vision from any past refractive surgery: LASIK, PRK, RK, etc.

"Sometimes patients complain about vision quality problems, such as not being able to see in dim or low light. This is referred to as poor contrast sensitivity," said Roger Steinert, MD, associate clinical professor of ophthalmology, Harvard Medical School.

"Prior to the advent of wavefront measurements, there wasn't anything we could do to measure or treat higher-order aberrations," Steinert said. "With this technology breakthrough, we can now measure these disorders, show the patient what's going on in their eye, link that information to the laser, and actually correct higher-order aberrations that diminish contrast sensitivity. Wavefront technology enables the surgeon to improve overall vision quality better than in the past."

Not all refractive surgeons agree that wavefront-guided LASIK can treat higher order aberrations. In fact, some surgeons argue that both wavefront LASIK and conventional LASIK can sometimes cause these aberrations because of artificial changes made to the natural shape of the eye's surface. However, wavefront-guided LASIK may be less likely to induce higher order aberrations than conventional LASIK, according to discussion in the April 15, 2005 issue of Ophthalmology Times.

A 2005 survey revealed that most refractive eye surgeons now use wavefront-guided LASIK in their practices. Read more about the study in the sidebar:

Study Shows Improved Contrast Sensitivity After Wavefront-Guided LASIK

Refractive eye surgeons appear overwhelmingly to favor customized or wavefront LASIK as evidenced by results of a 2005 American Society of Cataract and Refractive Surgery (ASCRS) survey of 4,645 U.S. members (16 percent responded). About 74 percent of refractive surgeons now use wavefront-guided LASIK in their practice, compared with fewer than 10 percent in 2003.

In certain cases, outcomes such as improved night vision with use of wavefront-guided LASIK appear to surpass results that can be achieved with conventional LASIK.

In August 2004, the U.S. Navy announced that patients at its refractive surgery center were achieving better distance vision and night vision after custom LASIK than after traditional LASIK. Read more about the U.S. Navy study.

In a small study, 88 percent of contrast sensitivity measurements improved after wavefront-guided LASIK, while only 40 percent improved after regular LASIK. This was one month after surgery.

Uncorrected visual acuity of 20/20 or better was achieved by similar numbers, however: 72 percent of the wavefront group and 70 percent of the regular LASIK group. The study was published in the March 2004 issue of Ophthalmology, the clinical journal of the American Academy of Ophthalmology. — L.S.


FDA-Approved Custom LASIK Systems
Laser System
and Manufacturer
FDA-Approved
Indications
Features
LADARVision 4000 with CustomCornea
&
LADAR6000 with CustomCornea (Alcon)
Myopia: up to -8 D with or without myopic astigmatism up to -4 D

Hyperopia and hyperopic astigmatism: up to +5 D (near vision problems) and astigmatism causing distance vision problems up to -3 D
Eye tracking, integrated wavefront, small spot system for precise laser application, no pupil dilation needed for treating larger optical zones in LADAR6000 system
Technolas 217z Zyoptix System
(Bausch & Lomb)
Myopia: up to -7 D with or without up to -3 D myopic astigmatism and total refractive error equal to or less than 7.5 D Integrated wavefront and "flying spot," meaning fast, uniform application of laser beam with each pulse for smooth corneal surface
Star S4 Active Trak with CustomVue
(Visx)
Myopia: up to -6 D, with or without up to -3 D myopic astigmatism

Hyperopia: up to +3 D with or without up to +2 D for hyperopic astigmatism
Eye tracking, integrated wavefront, no pupil dilation required, which speeds up procedure, unique wavefront analysis system known as Fourier for increased resolution
Star S4 IR with CustomVue
(Visx)
Myopia: up to -6 D with or without up to -3 D of myopic astigmatism

Hyperopia: up to +3 D with or without up to +2 D of hyperopic astigmatism

Mixed astigmatism: up to 5 D
Same as S4 Active Trak
Allegretto Wave with Allegro Analyzer
(WaveLight)
Myopia: up to -7 D with or without up to 3 D of astigmatism Scanning spot system, eye tracking, integrated wavefront, algorithm (mathematical measurement) based on population studies that helps minimize possibility that a vision error known as spherical aberration might be induced during vision correction
Note: D refers to diopters.

How Custom LASIK Works

The surgeon in one popular method will begin by using the wavefront device to transmit a safe ray of light into your eye. The light is then reflected back off the retina, out through the pupil, and into the device, where the reflected wave of light is received and arranged into a unique pattern that captures your lower- and higher-order aberrations.

All of these visual irregularities are then displayed as a 3-D map, referred to as a wavefront map. This information is then electronically transferred to the laser (in wavefront-guided systems), and computer-matched to the eye's position, enabling the surgeon to customize the LASIK procedure to your unique visual requirements.

Getting Wavefront-Guided Custom LASIK

Numbers of LASIK procedures in general grew significantly in 2004 and 2005, with many leading LASIK surgeons reporting in publications such as EyeWorld (published by the American Society of Cataract and Refractive Surgery) that most eligible patients were opting for more expensive custom LASIK. The advent of custom LASIK also appears to be contributing to increased public interest in undergoing LASIK. Review of Optometry in its October 2004 edition predicted about 1.35 million total LASIK procedures would be performed in the United States by the end of the year, up from 1.15 million procedures in 2003. About 1.45 million U.S. LASIK procedures were predicted for 2005*, though analysts feel that number may be revised because of fewer than expected procedures being performed in southern states that were affected by Hurricane Katrina. A 2006 Staar Surgical report estimates that about 1.4 million LASIK procedures currently are performed annually in the United States, about half of all procedures worldwide.

Custom LASIK usually costs significantly more than traditional LASIK, partly because a fee is paid to the device manufacturer for each procedure. For more information on custom LASIK pricing, please see our article on the cost of refractive surgery.

Research is continuing into expanding the degree of vision errors (such as high myopia) that can be corrected with custom LASIK. Investigations also are underway for use of custom LASIK to create multifocal corrections, which would enable older eyes that have developed presbyopia to see at near, middle, and distant ranges at the same time.

Like conventional LASIK, custom LASIK won't cure all vision-related problems, so it's important to discuss its applications with your eye doctor or surgeon to determine if you are a good candidate.

*Source: IntraLase Corporation annual report for 2004

[Page updated June 2007]
